ELITE NEW ENERGY MAKES GREENER LIFE
5 Years
| Ask Lasest Price | |
| Brand Name : | Elite Battery |
| Model Number : | 12V 100Ah |
| Certification : | CE, UL, MSDS, UN38.3, MSDS |
| Price : | $59.99-$269.99/PCS |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal |
| Supply Ability : | 10000 PCS/Month |
| Delivery Time : | 30 Days |
1280Wh 12V 100Ah LFP Lifepo4 Caravan Battery Pack Optional Bluetooth
12V 100Ah LFP Battery Lithium Battery Pack For Caravan Backup Battery
Feature
1. High safety and stable performance.
2. 2000+ cycles at 100% DOD.
3. Smaller and lightweight than lead acid battery
4. The BMS features with automatic protection against over-voltage, over-current, over-discharge and over temperature.
5. Wide applicable operating temperature range from -20°C to +65°C.
6. Lithium iron phosphate battery is a environment friendly green energy storage.
Battery Parameter
Nominal Voltage | 12.8V |
Nominal Capacity | 100Ah |
Energy | 1280Wh |
Internal Resistance | ≤10mΩ |
Cycle Life | >3000 cycles@1C 100% DOD |
Months Self Discharge | <3% |
Efficiency of Charge | 100%@0.5C |
Efficiency of Discharge | 96-99% @1C |
Charge Cut-off Voltage | 14.6±0.2V |
Charge Mode | 0.2C to 14.6V, then 14.6V charge current to 0.02C(CC/CV) |
Recommend Charge Current | 20A |
Max. Charge Current | 100A |
Max. Continuous Discharge Current | 100A |
Max. Pulse Current | 200A(10S) |
Discharge Cut-off Voltage | 10V |
Charge Temperature | 0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity |
Discharge Temperature | -20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity |
Storage Temperature | 0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity |
Water Dust Resistance | IP54 |
Cell&Method | 4S |
Package | Plastic ABS case |
Dimensions(in./mm.) | 329*172*219mm |
Weight(lbs./kg.) | 14.7kg |
Led Indicator | Optional |
Wide Application
1. Storage: Wind & Solar energy storage, home energy storage；etc;
2. Telecom: Transmission base, Communication power, Telcom Base,etc;
3. UPS : Medical Instrument, Military power, Computer Server Center；etc;
4. Backup: Touring car, Caravan,Marine, Yacht,etc;
5. Others: Electric Golf Car, Electric forklifts, Engine Starting Battery, Commercial Bus and Transit (E-car, E-bus, Golf car, E-bike, Scooter, AGV, Wheelchairs, E-truck, E-sweeper,etc;
FAQ
Q1: What is your MOQ?
A1: Sample order is available , welcomed.
Q2: Could you send me your catalog and price list?
A2: We have full kinds of battery which feature different voltage and capacity, Please kindly send us your requirement.
Q3: How can I choose a right battery?
A3: Please feel free to contact us with your requirement then our
sales will recommend you the suitable product.
Q4: What is your warranty policy?
A4: We offer 2 years warranty for our products and can be replaced with new ones for free if quality Issues
Q5: How to solve the technical problem?
A5: We will solve your problem within 24 hours and provide on line
technology support.
Q6: What payment terms ?
A6: We accept T/T, Paypal, Money Gram etc.
|
|
