ELITE NEW ENERGY MAKES GREENER LIFE
5 Years
| Ask Lasest Price | |
| Brand Name : | Elite Battery |
| Model Number : | 48V 100Ah |
| Certification : | CE, UL, MSDS, UN38.3, MSDS |
| Price : | $199.99-$1199.99/PCS |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal |
| Supply Ability : | 10000 PCS/Month |
| Delivery Time : | 30 Days |
48V 51.2V 100Ah Lithium Ion Battery Solar Wall Mounted Powerwall
48V 51.2V 100Ah Lithium ion Battery Wall-mounted Powerwall Battery Solar LiFePO4 Battery Pack
| Electrical Characteristics | Model | ELT-PW-5K | ELT-PW-10K | ||||
| Nominal Voltage | 51.2V | ||||||
| Nominal Capacity | 100Ah | 200Ah | |||||
| Energy | 5120Wh | 10240 | |||||
| Battery Type | LiFePO4 Battery | ||||||
| Internal Resistance | ≤10mΩ | ||||||
| Life Span | >6000 cycles | ||||||
| Months Self Discharge | <3% | ||||||
| Efficiency of Charge | 100%@0.5C | ||||||
| Efficiency of Discharge | 96-99% @1C | ||||||
| Standard Charge | Charge Cut-off Voltage | 58.4±0.2V | |||||
| Charge Mode | 0.2C to 58.4V, then 40V charge current to 0.02C(CC/CV) | ||||||
| Recommend Charge Current | 20-50A | ||||||
| Max. Charge Current | 100A | 200A | |||||
| Standard Discharge | Max. Continuous Discharge Current | 100A | 200A | ||||
| Max. Pulse Current | 150A | 300A | |||||
| Discharge Cut-off Voltage | 40V | ||||||
| Environmental | Charge Temperature | 0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity | |||||
| Discharge Temperature | -20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity | ||||||
| Storage Temperature | 0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity | ||||||
| Water Dust Resistance | IP67 | ||||||
| Mechanical | Package | Metal Case | |||||
| Dimensions(in./mm.) | 450*163*750mm | 520*163*880mm | |||||
| Weight(lbs./kg.) | 55kg | 100kg | |||||
Parallel Connection | YES | ||||||
| Others | Certification | CE, MSDS, UN38.3 | |||||
| Warranty | Standard 5 years, 10+ years upon request | ||||||
| OEM | Support for customized dimension, current, logo and so on. | ||||||
Solar Powerwall Battery
Deep Cycle
Elite's deep cycle lifepo4 batteries have unlimited mounting capability, exceptional longevity, and are more cost effective.
Multiple applications
The batteries can be connected in parallel connection to be max 160kwh. Perfect for home solar system, on grid and off grid.
Easy installation:
It is lightweighe and compact size that able to safely mount in any position on the wall.
Integrated Function
The powerwall can be installed in parallel and it built-in integrated BMS communication protocol to comprehensive hybrid and off grid inverters
Wide Application
The lithium Ion powerwall series are widely used in Solar Systems for residential and commercial use.Connect with solar panel and inverter, conversion of direct current to alternating current to supply the energy power to the home appliances.
Packaging & Shipping
Package: With high quality pearl wool, UN cartons / Plywood, plastic pallet.
Shipping: By air, by sea, by express, railway transportation and so on.
FAQ
1). Can you supply OEM &ODM service ?
Yes, please feel free to contact us with your requirements.
2).What kind of certificates your products have acquired ?
We have CE, MSDS, UN38.3 certifications for all of our products. If you require specific certification, please contact us.
3).How do you ship the goods since they are high capacity battery ?
We have long-term cooperated forwarders who are professional at battery shipment.
4).How can I do if I need more help for the order?
You can chat our sales online or send inquiry email,we will respond you ASAP
5). Do you have MOQ?
No, welcome your trail order.
6). How to order?
1.If you are interested in any products,please tell us the model No,detailed parameter, we will quote you in time.
2.After confirmation of the price, we will make the PI for you.
3.After receiving your deposit,we will arrnge shipment for you.
4. After shipment, we provide you with the bill of tracking number.
|
|
