ELITE NEW ENERGY MAKES GREENER LIFE
5 Years
| Ask Lasest Price | |
| Brand Name : | Elite Battery |
| Model Number : | 51.2V 105Ah |
| Certification : | CE, UL, MSDS, UN38.3, |
| Price : | $299.99-$2599.99/PCS |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal |
| Supply Ability : | 10000 PCS/Month |
| Delivery Time : | 30 Days |
| Electrical Characteristics | Nominal Voltage | 51.2V |
| Nominal Capacity | 105Ah | |
| Energy | 5376Wh | |
| Internal Resistance | ≤10mΩ | |
| Cycle Life | >6000 cycles@1C 100% DOD | |
| Months Self Discharge | <3% | |
| Efficiency of Charge | 100%@0.5C | |
| Efficiency of Discharge | 96-99% @1C | |
| Standard Charge | Charge Cut-off Voltage | 58.4±0.2V |
| Charge Mode | 0.2C to 58.4V, then 58.4V charge current to 0.02C(CC/CV) | |
| Recommend Charge Current | 55A | |
| Max. Charge Current | 100A | |
| Standard Discharge | Max. Continuous Discharge Current | 200A |
| Max. Pulse Current | 400A(35S) | |
| Discharge Cut-off Voltage | 40V | |
| Environmental | Charge Temperature | 0ºC to 45ºC(32F to 113F)@60±25% Relative Humidity |
| Discharge Temperature | -20ºC to 60ºC(-4F to 140F)@60±25% Relative Humidity | |
| Storage Temperature | 0ºC to 40ºC(32F to 104F)@60±25% Relative Humidity | |
| Water Dust Resistance | IP67 | |
| Mechanical | Cell&Method | 16S |
| Package | Metal case | |
| Dimensions(in./mm.) | 509*334*230mm | |
| Weight(lbs./kg.) | 45kg | |
| Terminal | M8 | |
| Display screen | Optional | |
| Bluetooth | Optional |
BMS Protection
1.Over charged protection
2.Over discharged protection
3.Thermal protection
4.Over current protection
5.Cell balancing
Five-Year-Warranty
1. We want you to be fully satisfied with every item that you purchase from Elite
2. Furthermore, we also provide five-year warranty for batteries.
3. And if any quality problems, not caused by improper use or man-made, Elite will replace it one by one.
We Promise
1.All products will be tested 100% before shipment to ensure that the product does not have any quality problems.
2.We guarantee that within 12 months from the date of receipt of the goods, we will not include man-made damage. If there is any
quality problem, we will provide return service.
Packaging & Shipping
With high quality pearl wool, UN cartons / Plywood, plastic pallet.
Standard batteries lead time: Samples: 15-20 days, Bulk order:
25-30 days.
Customized batteries lead time: Samples: 30-40 days, Bulk order:
30-40 days.
Shipment:By air, by sea, by express, by railway, etc.
4:How do I choose the correct lithium deep cycle battery for my application?
In most standard 12, 24, or 48 volt systems the best choice of lithium battery is LiFePO4 (Lithium Iron Phosphate). The voltage of this type of battery is very similar to an AGM and will work great with readily available system components for your RV, boat, or off-grid power system.
|
|
