    High Capacity 48V 200Ah Li Ion Battery Pack 10kwh LiFePO4 Battery Powerwall

    Ask Lasest Price
    Brand Name : Elite
    Model Number : 48V 200Ah 10kWh Powerwall
    Certification : CE, UL, MSDS, UN38.3, MSDS
    Price : $599.99-$2199.99/PCS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram,Paypal
    Supply Ability : 10000 PCS/Month
    Delivery Time : 20-30 Days
    • Product Details
    • Company Profile

    High Capacity 48V 200Ah Li Ion Battery Pack 10kwh LiFePO4 Battery Powerwall

    High Capacity 48V 200Ah Li-ion Battery Pack 10kwh LiFePO4 Battery Powerwall


    10kwh Powerwall Battery


    48V 200Ah Battery Parameter


    MODELELT48200
    ELECTRICAL SPECIFICATIONS
    Cell Type - ChemistryPrismatic- LiFePO4
    Rated Capacity200Ah
    Rated Voltage51.2V
    Energy10240Wh
    Resistance30mΩ
    Self Discharge<1.5% per month
    Maximum Modules in Parallel16
    MECHANICAL SPECIFICATIONS
    Dimensions (L x W x H)880*163*520mm
    Weight100Kg
    Enclosure ProtectionIP65
    DISCHARGE/CHARGE SPECIFICATIONS
    Discharge Cut-off Voltage40V
    Max Continuous Discharging Current100A
    Peak Discharge Current130A for 3 seconds
    Recommended Discharge Current100A
    CHARGE SPECIFICATIONS
    Charging Limited Voltage58.4V
    Max Charging Current100A
    Recommended Charge Current20A
    TEMPERATURE SPECIFICATIONS
    Charge Temperature Range0~45ºC
    Discharge Temperature Range-20~60ºC
    Recommended Operating Temperature15~35ºC
    Storage Temperature & Humidity Range
    (Less than 1 month)
    -20~35ºC, 45~75%RH
    Storage Temperature & Humidity Range
    (Less than 3 months)
    -10~35ºC, 45~75%RH
    Recommended Storage Temperature & Humidity Range15~35ºC, 45~75%RH
    OEM
    Available on request

    Battery Appearance



    Packaging & Shipping

    With high quality pearl wool, UN cartons / Plywood, plastic pallet.

    Standard batteries lead time: Samples: 15-20 days, Bulk order: 25-30 days.

    Customized batteries lead time: Samples: 30-40 days, Bulk order: 30-40 days.

    Shipment:By air, by sea, by express, by railway, etc.


    Q&A

    Q1: Are you a manufacturing factory?

    A1: We are a lithium battery manufacturer from Shenzhen,China. Welcome to visit our factory and production process.

    Q2: What’s your product range?

    A2: We focus on Lithium-ion battery, Lithium iron phosphate (LiFePO4) battery for residential and commercial energy storage system, telecom tower, UPS, AGV, golf cart, boat, RV, camping, electric vehicle, etc.

    Q3: What is the production time for your lithium battery?

    A3: The sample delivery time is about 10-20 days. The bulk order delivery time is about 25-35days according to quantity.

    Q4: How do you guarantee the quality?

    A4: Always a pre-production sample before mass production. Always final Inspection before shipment.

    Q5.Which certificates do you have?

    A5:We have CE/UN38.3/MSDS ...etc.
